K series R

  • Independent LEDs, indicate the status of the battery

  • Activation of the transmitter is protected by an electronic key-code and an auto shut-off option which is programmable

  • The system automatically change to another frequency in the presence of radio interference

  • Eco power management system. Save on batteries

  • It can receive and display via 4 LEDs signals coming from the receiver (relay action feedback)

  • Mushrooms type EMO button

  • Internal BootLoader, up firmware to the date by using computer

  • Wireless pairing procedure using the keyboard pushbuttons

  • ​QI wireless charging pad is optional in New 2016 K plus series

Technical Data

Pushbutton

2, 4, 6, 8,10, 12 single / double pressure motion buttons



Weight

approx. 305g (2-8 buttons)

approx. 390g (10, 12 buttons)



Size

193×57×51mm(2-8 buttons)

230×57×51mm(10, 12 buttons)

Frequency band

315 / 418 / 429 / 433 / 447 / 470 / 915 MHz / 2.4 GHz

Channel space

12.5 kHz

Number of available on/off command

max. 24 + Start and EMO

Hamming distance

≥ 15

Radio communication

bi-directional

Frequency handling

Automatic and dynamic switching between 2 channels

Power supply

LR6(AA)1.5V / NiMH(AA)1.2V x2

Stop command response time

~ 50 ms

Command response time

~ 50 ms

Protection degree

IP65

Operating and storage temperature

(-25°C)~(+55°C) / (-40°C)~(+85°C)

Housing material

PA6 (GF30%)

Features

Incredibly Control Dial

The control dial can adjust the output from 0 to 10 volts.

EX:

3 volts - slow speed

More than important

The rubber protective cover under the EMO button is designed to against dust and small rocks falls. This designed avoids small rocks jam when emergency is happened!

Details are important

The stainless legs on the back of K series give the case plenty of lay-on-the-ground protection for increasing the lifetime of the housing.

10 volts - fast speed

Stronger than ever!

K series, One of the most shock resistant transmitter, is constructed of an ultra-high impact resistant comer bumper.

The corners of K series are reinforced for firmer grip and added protection in case of drop.

Non-slip yet durable

The backside of K series constructed like a new set of track tire. A matte black rubber-tone finish is durable and offers a secure grip.
